P7.8 Transparent LED Display for Shop Windows | High-Resolution | 8m viewing distance
Slim and lightweight design
Vivid high-resolution display
Energy-efficient LED technology
Radiant P7.8 Transparent LED Display
Engineered for premium commercial displays, the Radiant P7.8 Transparent LED Display redefines storefront engagement with its cutting-edge optical technology.
2500-5000nits adjustable brightness
Boasting 2500-5000nits adjustable brightness and 70% transparency index, this innovative solution delivers cinematic-grade 16-bit color depth visuals while maintaining window functionality – a breakthrough for fashion retailers requiring both product visibility and dynamic digital overlays.
Ultra-Slim Architecture
-
5kg/㎡ Featherlight DesignSeamless storefront integration
-
16384 dots/m² DensityHD clarity at 8m+ viewing
-
IP43 Aluminum CompositeDust/water resistant construction
Smart Energy System
250-800W
Dynamic Power Range
100-240V
Global Voltage
3840Hz
Refresh Rate
1/4 CC
Current Driving
Operational Excellence
-10℃~+50℃ thermal tolerance for extreme climate installations
100,000-hour lifespan with 140° viewing angle
Novastar system enables real-time content updates
Dual maintenance access (front & rear) for quick service
Details Specification
| Item | RDT-TP7.8 | Pixel Pitch | 7.8mm x 7.8mm |
| Module size | 500mm x 125mm | Cabinet size | 1000mm x 500mm |
| Cabinet Resolution | 128 x 64 pixels | Cabinet Weight | 5 kg |
| Physical Density | 16384 dots/m² | Brightness | 2500-5000nits |
| Driving Mode | Constant Current 1/4 | Refresh Rate | 1920-3840 Hz |
| Working Voltage | 100-240V AC, 50&60Hz | Gray Level | 16 bit |
| Maximum Power Consumption | 800W /m² | Average Power Consumption | 250W /m² |
| Protection Level | IP43 | Viewing Distance | >8m |
| Working Temperature | -10℃~ +50 ℃ | Working Humidity | 10 – 95 % RH |
| LED Life(Normal Tep) | 100,000 Hours | Viewing Angle | 140°/140° |
| Application | Indoor install outdoor view | Installation Type | Fixed installation |
| Maintenance Method | Front and rear | Software System | Novastar |
